Portable 8 bands IED Bomb Jammer( Professional)

Portable 8 bands IED Bomb Jammer( Professional)

    • Portable 8 bands  IED  Bomb Jammer( Professional)
    • Portable 8 bands  IED  Bomb Jammer( Professional)
    • Portable 8 bands  IED  Bomb Jammer( Professional)
    • Portable 8 bands  IED  Bomb Jammer( Professional)
    • Portable 8 bands  IED  Bomb Jammer( Professional)
    • Portable 8 bands  IED  Bomb Jammer( Professional)
    • Portable 8 bands  IED  Bomb Jammer( Professional)
  • Portable 8 bands  IED  Bomb Jammer( Professional)

    Product Details:

    Place of Origin: China
    Brand Name: JYT
    Certification: CE
    Model Number: JYT-DP8001

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 set
    Price: negotiate
    Packaging Details: netural package
    Delivery Time: 7-10 working days
    Payment Terms: T/T,Western Union
    Supply Ability: 100pcs/month
    Contact Now
    Detailed Product Description
    Material: Pelican Case RF Output: 27MHz, 35Mhz, 41MHz, 72MHz Toys And HM Remote Contro,Low-power Transmitters,Walky-Talky, 315/433MHz Car Remote Control,CDMA,GSM,PCS,DCS,3G,4G
    Total Power Output: 400W~700W Jamming Range: 300 To 500 Meters

    Portable 8 bands IED Bomb Jammer( Professional)



    JYT-DP8001 is high power IED bomb jammer.It has a wide convering of frequencies between 20MHz to 6000MHz.

    Parameter Shielding Range: 300-500 meters(-75dBm,depending on the distance of base station in an open filed)
    Transmission Power: Integrated Equipment≥760W,each channel≥80W



    Portable 8 bands  IED  Bomb Jammer( Professional)

    Portable 8 bands  IED  Bomb Jammer( Professional)



    Output Channel: 8 output channels



    Features
    *Ultra-wideband jamming coverage; continuously jamming wireless signals 20MHz~6000MHz
    *Draw-bar box designed for portability and easy moving;
    *Manual switch and remote control;
    *Each channel module can start or close individually;
    *Efficient frequency division ensures the best interference effect on signals of different frequencies;
    *Efficient power distribution minimizes power loss and improves efficiency; the power can be regulated as needed ( optional gear regulation);
    *Military standard casing, which is anti-throw, pressure-resistant and durable;
    *AC110-220V/External Battery;
    *Built-in efficient cooling fan and cooling fin ensures the product work stably in a long service life



    Main Parts
    Host*1
    Omni Antennas*8
    Line Control*1
    External Battery*1





    Component Dimensions



    Name L W H Remarks
    Host 650 509 357 Protrusions excluded
    Antenna

    760 Φ35



    Other Parameters

    Net Weight 39.4kg
    External Battery Weight 23.4kg
    Total Weight 90kg Aviation Case included
    Ambient Temperature -10℃~+50℃
    Relative Humidity ≤80%
    Power Consumption ≤360W
    Power Input AC100~240V,DC27V
    External Battery 28.5V,95AH,,extrernal battery can used for 90 minutes .Limited charge voltage:32.85V
    Antenna Parameters Omni antennas gain: 5dBi
    Switch Control Manually
    Equipment Chassis Metallic Paint





















































    Product Applications

    high capacity battery and portable backpack design make this jammer applicable to meeting halls,infantry,military security force,SWAT team,bomb squad,anti-terrorism units,anti-drag units,anti-riot force,the EOD team,checkpoints,

    hostage negotiations,border control,etc...



    Product details

    Portable 8 bands  IED  Bomb Jammer( Professional)

    Contact us for more Detailed Techinical Specification!
